compact Kinco frequency inverter CV20-2S-0007G (0.75 kW) single phase 230 VAC

Do you have questions? Our community may have already answered them!
Connect with others in our support forum.

1 Review

compact Kinco frequency inverter CV20-2S-0007G (0.75 kW) single phase 230 VAC

0,7 kW Nennleistung
Eingang 230 VAC einphasig
Ausgang Motor 230 VAC dreiphasig
V/F-Regelung
Modbus RTU

€78.99*

Prices excl. VAT plus shipping costs

No longer available

Product no.: KII.CV20.2S.0007G

Hersteller: Kinco

Herstellernr.: CV20-2S-0007G

Product no.: KII.CV20.2S.0007G

Manufacturer no.:

CV20-2S-0007G

Manufacturer

Kinco

Create PDF quotation

Create PDF quotation for this product Hint: You can add multiple products to the cart and create a quotation in the cart. For logged in users the link will generate a quotation with their address.

Customers also bought

Kinco KS133-06IV Analog expansion for KS105 PLC

From €88.57 *

No longer available

Preis exkl. MwSt., zzgl. Versandkosten

Kinco KS122-12XR Digital Output Expansion for KS105 PLC

€53.78 *

No longer available

Preis exkl. MwSt., zzgl. Versandkosten

Kinco frequency converter FV20-4T-0037G (3.7 kW) three-phase 400 VAC

€226.05 *

No longer available

Preis exkl. MwSt., zzgl. Versandkosten

Serial connection cable (RS-485) for Kinco CV20 frequency converter - open ends

€12.00 *

No longer available

Preis exkl. MwSt., zzgl. Versandkosten

Kinco MK070E-33DT 7" IoT Series HMI Touch Panel with Ethernet and Integrated PLC

From €167.38 *

No longer available

Preis exkl. MwSt., zzgl. Versandkosten

Customers also viewed

compact Kinco frequency converter CV20-2S-0015G (1,5 kW) single phase 230 VAC

€92.44 *

No longer available

Preis exkl. MwSt., zzgl. Versandkosten

compact Kinco frequency inverter CV20-2S-0004G (0.4 kW) single phase 230 VAC

From €67.31 *

No longer available

Preis exkl. MwSt., zzgl. Versandkosten

Compact Kinco Frequency Inverter KC100 0.4 kW Single-Phase 230 V AC

From €58.37 *

No longer available

Preis exkl. MwSt., zzgl. Versandkosten

Compact Kinco Frequency Inverter KC100 0.75 kW Single-Phase 230 V AC

Variants from €58.37 *

From €60.80 *

No longer available

Preis exkl. MwSt., zzgl. Versandkosten

Product information "compact Kinco frequency inverter CV20-2S-0007G (0.75 kW) single phase 230 VAC"

Frequency converter single-phase 230 VAC, 50Hz/60Hz in the

Manufacturer "Kinco"

Kinco is one of the leading manufacturers of automation technology in Asia. The company's research and development team is based at its headquarters in Shenzhen (China) on the border with Hong Kong, and Kinco also operates a research center in Germany, a unique feature among Chinese companies.

In terms of quality and range of functions, Kinco is strongly oriented towards the European and German markets. Communication drivers for Siemens S7 controllers are therefore included in every HMI. The company has a modern and reliable range of HMIs, drive technology and controllers. Kinco already generates more than 10% of its turnover internationally, and Germany is one of the manufacturer's growth markets.

Open manufacturer website

Technical Specifications

Electrical properties
EMC input filter:	integrated
Efficiency:	>= 93 %
Frequency range:	0 – 300 Hz
Frequency resolution:	0.01 Hz
Input current (rated current):	8,2 A
Motor output current (rated current):	4,0 A
Nominal Supply Voltage:	230 V AC single-phase (50 / 60 Hz)
Overload capacity:	180% rated current for 10 seconds , 150% rated current for 1 min
Permissible Voltage Range:	180 – 260 V AC
Rated power:	0.75 kW
Digital I/O
Digital Inputs (Quantity & Type):	4 (24 V DC NPN) , Function programmable
Digital Outputs (Quantity & Type):	1 relay (configurable)
Relay outputs (number & type):	1 (configurable)
Analogue I/O
Analog Inputs (Designation & Type):	0 – 10 V , 0 – 20 mA
Analog Inputs (Quantity):	1
Analog Outputs (Quantity):	none
Interfaces, protocols and connections
CANopen:	no CANopen
Ethercat:	no Ethercat
Ethernet:	No Ethernet
Fieldbus & Protocols:	Modbus RTU slave
Free serial communication:	No
Interfaces:	RS-485
Isolated Serial Interface:	no
Modbus:	Modbus RTU slave
Profibus DP:	No Profibus
RS-485 connection type:	RJ11
SD card:	none
Serial connections:	Port 1: RS-485
Terminal Type:	Screw terminal
Other properties
Acceleration types:	S-curve , linear
Brake:	without mechanical motor brake
Control:	Buttons on the device , Digital inputs (configurable) , Modbus RTU
Control types:	V/f control
Frequency setting via:	Analog input , Built-in potentiometer , Digital inputs (configurable) , External potentiometer , Modbus RTU
Product Series:	CV20
Protection Functions:	Overcurrent protection , Overheating protection , Overload protection , Overvoltage protection , Undervoltage protection
Dimensions and environmental properties
Cooling:	Fan (active)
Dimensions (Width x Height x Depth):	68 mm x 132 mm x 131 mm
Housing Material:	Engineering plastic
Mounting:	DIN rail , Screw mounting
Operating Temperature Range:	-10 °C to +40 °C , Lower output in the 40 °C to 50 °C range
Protection Rating:	IP20
Storage Temperature Range:	-40 °C to +70 °C
Weight:	0.8 kg
Programming
Configurable via:	Buttons on the device , Kinco Software , Modbus RTU
Language of the programming environment:	Chinese , English
Motor Parameter Autotuning:	no
Programming software:	Kinco Inverter
Certifications
CE Certificate:	Yes
Standards and Certifications:	CE (EN61000-6-4:2007+A1:2011, EN61000-6-2:2005)
