Wir und unsere Partner unterstützen Sie bei der Programmierung Ihrer SPS und der Erstellung von Visualisierungen für Ihr HMI. Egal ob Kontaktplan oder Anweisungsliste, wir konvertieren bestehende SPS-Programme für Sie. Auch komplette Maschinen- und Anlagenvisualisierungen erstellen wir gern nach Ihren Vorgaben.
Haseg
The company Haseg has been successfully active in the automation environment since 2001. Home automation, heating and solar systems are the main focus.Contact details:HASEG Haustechnik*Automatisierung*ServiceInh. Ulrich GlaschkerHeidestr. 101945 GrünewaldService@haseg.dehttp://www.haseg.de/Tel.: 49 (0) 35754 17146Fax: 49 (0) 35754 17148Radio: 49 (0) 177 2602337 .
Lars Schlicht - Simply Schlicht
Lars Schlicht is an experienced programmer for PLC and HMI. Home automation and metalworking are
Conversion of an existing Mitsubishi-FX PLC program to Tiger PLC per line ladder diagram (KOP)
€0.50*
We convert your existing Mitsubishi-FX project to Xinje XD or XL very cheap.We need a file with the IL project. .
- Available
- Delivery Time : 14-31 days
Applying your individual front foil for Kinco HMI
€9.80*
We glue your HMI optionally with your individual foils. You must order the foils separately. This order item is a service for the application. Alternatively, you can also order the foils directly from us and apply them yourself. To apply the films have a removable adhesive surface..
- Available
- Delivery Time : 3-5 Tage
Online advanced training for Kinco DTools (Teamviewer 90 minutes)
€15.97*
90-minute teamviewer training (live) on advanced features of Kinco DTools. Next date Friday, March 11, 2022 10:00 am to 11:40 am (with break).
With this training you will learn how to program the Kinco Green Series HMI with the German software version of Kinco DTools. This training builds on the basic training and shows advanced concepts.
Contents of the advanced training:
Alarms.
Create and display events.
RecipesFile system and FTP.
Present PDF files
Direct and indirect windows.
User management and rights.
To participate in the training, you can order it directly in the store. You will then receive from us the calendar date with the appropriate link. For the training you only need a PC with Internet connection. Camera or microphone are not needed, you can ask questions via chat.
If the date does not fit, but there is interest in the future, please send a short e-mail to service@spstiger.de. We will then inform you as soon as there is a new training date..
- Available
Online basic training for Kinco DTools (Teamviewer 90 minutes)
- 01:55 Hours of Video Material
- Unlimited Time of Use **
- 12 Lessons
Customized front film for Kinco GL070E
€16.97*
Customized film to stick on the Kinco GL070E without front film. We are happy to create the front films in custom design for you. The foils are produced in digital printing and have an adhesive surface to peel off and apply directly to the HMI. Minimum order of the foils is 25 pcs.
- Available
- Delivery Time : 3-4 weeks
Customized front film for Kinco GL070E UV resistant
€19.25*
Customized film to stick on the Kinco GL070E without front film. Particularly UV stable film with matte window against reflections This film is more suitable for places where there may be direct sunlight sometimes.We will be happy to create the front films in custom design for you. The foils are produced by digital printing and have an adhesive surface to peel off and apply directly to the HMI. Minimum order of the foils is 50pcs..
- Available
- Delivery Time : 3-4 weeks
Chinese translation of HMI project per image
€20.17*
For machine export: You have a HMI project for one of our HMI touchpanel and want to export a machine to China? We translate your HMI project for a touch panel from spstiger store into Chinese and build in a language switch.Our native translators will make sure that your customers in China understand your operation, can easily handle your machine and will be happy to buy it again.Send us the project as a zip file via email. You will receive the translated project with language switching back by email and only need to transfer it to your touch panel.
Send your project to service@spstiger.de.
Please include your order number so we can properly match the information.
If you don't have a project for one of our touch panels yet, you can order the creation right away.
- Available
- Delivery Time : 14 Tage
Customized front film for Kinco GL100E
€25.27*
Customized film to stick on the Kinco GL100E without front film. We are happy to create the front films in custom design for you. The foils are produced by digital printing and have an adhesive surface to peel off and apply directly to the HMI. Minimum order of the foils is 25 pcs.
- Available
- Delivery Time : 3-4 weeks
individual online short training (Teamviewer 30 minute blocks by appointment)
€41.18*
Half-hour individual Teamviewer training on a topic of your choice. Our professional programmers will work out a topic together with you on your PC. After booking, send us your desired topic in advance so that we can prepare it accordingly. We will then arrange a date.Here is a list of possible topics for inspiration:
Using timers and counters properly in the PLC.
Introduction to the variable areas of the PLC.
Introduction to the Thinget programming environment.
Introduction to the Kinco programming environment
Creating programs in the PLC
Using macros in the HMI
Configuring and using data loggers in the HMI
Use custom images and animations properly in the HMI.
...
...
- Available
Creation of an HMI from standard elements according to your specifications (Excel/scanned sketch) per image
€41.93*
We create an HMI project for touchpanel of one of our manufacturers for you according to your specifications. If you specify the PLC type and provide the graphic objects with addresses and notes, we bind them in the configuration right away.You will receive the project by email and only have to transfer it to the touch panel. We include simple instructions for this as well as a report on image creation with any deviations.This price only applies to standard components and graphics available in the software. We are happy to offer extended functions individually.
- Available
- Delivery Time : 14 Tage
Supplier research and support
€74.79*
We support you in supplier research, product selection, sample ordering and negotiation for the procurement of simple and complex technical equipment from abroad. We have particular expertise in the procurement markets of China and Taiwan.
- Available
Kinco GT070HE 7" IoT Series Widescreen HMI Touch Panel with Ethernet
From
€142.14*
The GT070HE is the IoT variant of the GL070E and a modern, versatile and very cost-effective HMI touch panel with 7'' screen diagonal and a resolution of 1024 * 600 pixels from Kinco with Ethernet interface. It has an integrated VPN remote maintenance and remote download function and automatically connects to a remote maintenance server in a network. It connects to a router via Ethernet.The resolution is higher than the GL070E and the same as the 10" HMI GT100E. This means that projects from the 7" device can also be transferred directly to the 10" device..
The HMI is programmed via the free software Kinco DTools. You can find this further down on this page as a download. The software is available in German language.
You can connect PLCs, frequency converters and other devices that you want to visualize or control via Ethernet and serial interface. The touch panel offers you a versatile range of functions and simple graphical configuration of PLC communication. The touch panel is ideal for machine controls or smaller plant control elements.
The device supports communication with over 60 different PLC models, including Siemens S7-200, S7-1200/1500, S7-300/400, LOGO!, Modbus RTU/TCP (Master and Slave), Allen Bradley, Thinget, Mitsubishi FX, Beckhoff ADS, BACnet and many others.
Features (excerpt):
Various graphic elements for display and operation.
Animations
Individual graphic elements and images possible.
Extensive data logging
Recipe management
VNC server and client for remote control (e.g. from smartphone or browser)
PDF display on the HMI (new)
User management and security
Alarms and events
Individual language switching for users programmable via text tables.
C macros for complex calculations
Program and recipe download via USB, USB stick or Ethernet
FTP server for retrieving CSVs and log files
XY graphs with up to 64 characteristics possible, histograms.
Generation and display of QR codes
Scheduler for calendar controlled functions.
...
Note for new customers: You can test this device 30 days without obligation. This device is of course also available for existing customers to order normally at the price shown.This is how the test works for new customers: the first time you order this device, we offer you a 30-day return policy. Within 30 days, you can return this device to us as a first-time buyer. You will pay the invoice only after the trial period is over, if you have decided to use the device. To do so, order this device normally, we will automatically ship initial orders as a trial device. If you have any technical questions during the trial, feel free to write to us at support@spstiger.de.
Kinco HMI are now in use at well over 100 of our customers in Germany.We are convinced that Kinco's HMI touch panels also open up a particularly cost-effective way for you as an automation or machine and plant manufacturer to provide your customers with modern and versatile operator interfaces..
- Available
- Delivery Time : 2-5 days
Kinco GL150E 15" Green Series HMI Touch Panel
From
€691.43*
Modern and versatile and very cost effective HMI touch panel with 15'' screen diagonal and a resolution of 1,024 * 768 pixels from Kinco with Ethernet interface. The GL150E is the successor model of the MT4720TE and is compatible in terms of installation dimensions..
Through Ethernet and serial interface, you can connect PLCs, frequency converters and other devices that you want to visualize or control. The touch panel offers you a versatile range of functions and simple graphical configuration of PLC communication. The touch panel is ideal for machine controls or smaller plant control elements.
The device supports communication with over 60 PLC models, including Siemens S7-200, S7-1200, S7-300/400, S7-1500, Modbus RTU/TCP (master and slave), Allen Bradley, Thinget, Mitsubishi FX and many others. For more details, please refer to the "PLC Driver" tab.
Features (excerpt):
Various graphical elements for display and operation.
Animations
Individual graphic elements and images possible.
Extensive data logging
Recipe management
VNC server and client for remote control (e.g. from smartphone or browser)
PDF display on the HMI (new)
User management and security
Alarms and Events
Individual language switching for users programmable via text tables.
C macros for complex calculations
Program and recipe download via USB, USB stick, or Ethernet
FTP server to retrieve CSVs and log files.
XY graphs with up to 64 characteristics possible, histograms.
Generation and display of QR codes.
Scheduler for calendar controlled functions.
...
Note for new customers: You can test this device for 30 days without obligation. This device is of course also available for existing customers to order normally at the price shown.This is how the test works for new customers: the first time you order this device, we offer you a 30-day return policy. Within 30 days, you can return this device to us as a first-time buyer. You will not pay the invoice until the trial period is over and you have decided to use the device. To do this, order this device normally, we will automatically ship initial orders as a trial device. If you have any technical questions during the trial, feel free to write to us at support@spstiger.de.
. Kinco HMI are now in use at well over 100 of our customers in Germany.We are convinced that Kinco's HMI touch panels also open up a particularly cost-effective way for you as an automation or machine and plant manufacturer to provide your customers with modern and versatile operator interfaces.
- Available
- Delivery Time : 3-5 Tage
