Kinco Future Series F2156E-TX with emergency stop

Quantity	Unit price
To 3	€1,248.00*
To 19	€1,185.60*
To 39	€1,123.20*
To 99	€1,060.80*
From 100	€998.40*

Prices excl. VAT plus shipping costs

Available, delivery time: 3 bis 5 Tage

Product number:

KIH.F2156E.TX

Manufacturer no.:

F2156E-TX

Manufacturer

Kinco

Create PDF quotation

Create PDF quotation for this product Hint: You can add multiple products to the cart and create a quotation in the cart. For logged in users the link will generate a quotation with their address.

Product information "Kinco Future Series F2156E-TX with emergency stop"

The Kinco F2156E-TX is a 15" HMI with emergency stop switch and capacitive touchscreen. It is programmed with the new DTools Pro software.

Electrical properties
Nominal supply voltage:	24 V DC
Permissible voltage range:	18 - 28 V DC
Power consumption:	15 watts
Display
Backlight:	LED
Brightness:	300 cd/m²
Contrast ratio:	1000:1
Display colors:	16,2 Mio.
Screen diagonal:	15.6" / 40 cm
Screen resolution:	1920 * 1080
Touchtype:	capacitive
Viewing angle stability (left / right / top / bottom):	89° / 89° / 89° / 89°
Interfaces, protocols and connections
CANopen:	no CANopen
Communication driver for PLCs:	Allen Bradley (Ethernet only) , BACnet (Ethernet only) , Beckhoff Twincat ADS (Ethernet) , Codesys V3 (Ethernet) , Kinco PLC (serial + Ethernet) , Mitsubishi FX (serial + Ethernet) , Mitsubishi Q (Ethernet only) , Modbus master and slave (serial + Ethernet) , Omron (Ethernet only) , Siemens LOGO! (Ethernet) , Siemens S7-200 (serial + Ethernet) , Siemens S7-300/400 (Ethernet only) , Siemens S7-1200/1500 (Ethernet) , Xinje XC (serial) , Xinje XD/XL (Ethernet only)
Ethernet:	1 x 10/100/1000 (RJ45)
Fieldbuses & protocols:	Ethernet , Free serial communication (ASCII) , Modbus RTU Master , Modbus RTU slave , Modbus TCP Master (Client) , Modbus TCP slave (server)
Free serial communication:	Yes
Interfaces:	Ethernet , RS-232 , RS-485 , USB host
MQTT:	Publisher (Client) , Subscriber (Client)
Modbus:	Modbus RTU Master , Modbus RTU slave , Modbus TCP Client (Master) , Modbus TCP server (slave)
OPC UA:	OPC UA Client , OPC UA Server
RS-232 connection type:	DB9 Male
RS-485 connection type:	DB9 Male
USB host ports:	1 x USB-Host
Dimensions and environmental properties
Assembly:	Tragarm-Montage
Brightness:	300 cd/m²
Cooling:	Ambient air (passive)
Housing material:	Metal
Operating temperature range:	0 °C to +50 °C
Protection class:	IP65
Storage temperature range:	- 20 °C to + 60 °C
Other properties
Memory:	1 GB RAM , 8 GB eMMC
Processor:	ARM Quad Core 1.8 GHz
Real-time clock:	Yes (synchronization with network time possible)
Year of market launch:	2025
Programming
Programming languages:	Graphical programming interface
Programming software:	Kinco DTools Pro
Certifications
CE certificate:	Yes

Passende Programmiersoftware

Kinco DTools Pro - free programming software for Kinco F2, G2 and GL2 series HMIs

€0.00*

Details

Manufacturer "Kinco"

Kinco is one of the leading manufacturers of automation technology in Asia. The company's research and development team is based at its headquarters in Shenzhen (China) on the border with Hong Kong, and Kinco also operates a research center in Germany, a unique feature among Chinese companies.

In terms of quality and range of functions, Kinco is strongly oriented towards the European and German markets. Communication drivers for Siemens S7 controllers are therefore included in every HMI. The company has a modern and reliable range of HMIs, drive technology and controllers. Kinco already generates more than 10% of its turnover internationally, and Germany is one of the manufacturer's growth markets.
